The GEM-STIM analog IF Series is a professional dual-channel stimulator designed for pain management applications. It is available for OEM manufacturing and private label branding to meet diverse market requirements.

The GEMORE new dual-channel analog IF with True Sine Wave. Not only can it set parameters accurately, but it also operates easily with simple knob or slide switches according to the prescription for patients' condition. This device has a large control panel, which is helpful for people who can easily set the parameters. The frequency keeps its setting value and would not be affected by temperature increase during treatment. Its output waveform is a real Sine Wave.



GM3A10IF



True Sine Wave



Interferential of quad polar

•
• Channel: Dual, isolated between channels

• Pulse Amplitude: 0-90mA peak to peak into 500 ohm load.

• Carrier Frequency:4000Hz fixed

• Modulating Frequency: Adjustable, from 4004Hz ~ 4160 Hz
• Pulse Duration:125 μ S

• Mode:4-160 bps adjustable;  1/1 abruptly shift;  6/6 abruptly shift; 10/10 ramped

• Waveform: Symmetrical balanced Sine wave

• Output Configuration: Two (2 electrodes) or Quad polar ( 4 electrodes)

• Interference Pulse Freq: 4-160 bps, adjustable 4 bps/step

• Sweep time: 15 sec

• Timer: 30 min preset

• Max charge per pulse: 22.5 micro-coulombs maximum

• Constant current

• Power consumption is very small after the timer is off

• Power: DC 9V adaptor

• Size:96(H)× 62(W) × 26(T) mm

• Weight: Approx. 125 g (including battery)

• Tolerance: +/-10%
